Grillo G85D Walking Tractor with Rotary Tiller

All our Grillo Machinery is Inspected, Assembled and Tested by our qualified engineers.

Please call 0208 520 3929 for a FREE delivery if you are in our local area London, Essex, part of Hertfordshire and part of Kent.

Product Description:

This model incorporates all the features of the G85 but has a built in Diff- lock which, when it is operated, will lock both drive wheels giving extra traction in difficult conditions. Tilling width options from 58 to 70cm Heavy duty professional all gear drive Handles adjustable in height and from side to side Petrol or Diesel engine options available Electric start option on Diesel engine Low Vibration levels 2 forward + 2 reverse gears Aggressive agricultural wheels

The Grillo G85D is a very powerful and a robust machine. With all Grillo walking tractors it features its own in- house built transmission with 2 forward and 2 reverse gears and is ideal for hard working conditions. The G85D has an easy to operate differential lock which provides increased traction when working in heavy ground or when ploughing for instance. Larger 4.00x10 wheels and tyres are standard on this model and the 58cm tiller head is the same as is used on our G85 model. Vibration damped handles for operator comfort are standard and they are also height adjustable with a facility which allows rotation from side to side. The powerful 8.5hp Subaru petrol engine is easy to start and extremely quiet in operation. As with all our walking tractors a number of useful attachments are available which makes it a true workhorse which will last for many years. Engine Robin Subaru EX27 OHC

Technical Specifications:

Engine Lombardini 15LD350

Start recoil starter

Supply diesel

Displacement 349 cc, 1 Cylinder

Power 7.5 HP (5.5 kW)

Air cooled

Dry air filter

Fuel tank capacity 6,1 L eng. EX 27 OHC - 4,3 L eng. 15 LD 350 - 5 L eng. 15 LD440

Transmission with oil bath gears

Gearbox With clutch engagement. The walking tractor version has 2 forward gears + 2 reverse gears. The sickle bar version has 2 forward gears + 2 reverse gears

Reverse gear unit by lever

Clutch conic active

Standard rotary tiller Adjustable rotary tiller with x 4 tines. Working width 580 mm

Hoes system diametre 315 mm

Working width Adjustable at 370 and 470 mm (680 mm with extension kit cod. 929112)

Working depth 16 cm

Item no. standard rotary tiller 984511

P.T.O. 965 rpm independent of the gearbox. Clockwise rotation for the walking tractor version, anticlockwise rotation for the sickle bar version.

Differential locking Differential with locking device by lever on the handlebar

Available tyres Pneumatic wheels tractor 4.00-8 (fixed disks), 4.00-10 (adjustable disks) and 5.00-10 (adjustable disks). Pneumatic wheels tractor 5.00-12 (adjustable disks) for plough kit. Wide steel wheels having diameter 40 x 10 cm. Pneumatic wheels garden 20x10.00-8 (extensions cod. 937112 needed)

Speed With 4.00-10 wheels 1st gear 1,2 km/h, 2nd gear 3,0 km/h

Service brake Brake drum (kit upon request cod. 978111)

Handlebar Height and side adjustment. Fitted on anti-vibration blocks

Safety devices Active clutch, reverse speed – PTO cut-out

Weight Weight: standard version 112 kg

Warranty 2 years
